| Screw Size | Major Diameter (inches) | Nearest Fraction | Major Diameter (mm) |
|---|---|---|---|
| #1 | 0.073″ | 5/64″ | 1.85 mm |
| #2 | 0.086″ | 5/64″ | 2.18 mm |
| #3 | 0.099″ | 3/32″ | 2.51 mm |
| #4 | 0.112″ | 7/64″ | 2.84 mm |
| #5 | 0.125″ | 1/8″ | 3.18 mm |
| #6 | 0.138″ | 9/64″ | 3.51 mm |
| #7 | 0.151″ | 5/32″ | 3.84 mm |
| #8 | 0.164″ | 11/64″ | 4.17 mm |
| #9 | 0.177″ | 11/64″ | 4.50 mm |
| #10 | 0.190″ | 3/16″ | 4.83 mm |
| #11 | 0.203″ | 13/64″ | 5.16 mm |
| #12 | 0.216″ | 7/32″ | 5.49 mm |
| #13 | 0.229″ | 15/64″ | 5.82 mm |
| #14 | 0.242″ | 1/4″ | 6.15 mm |
| #15 | 0.255″ | 1/4″ | 6.48 mm |
| #16 | 0.268″ | 17/64″ | 6.81 mm |
| #17 | 0.281″ | 9/32″ | 7.14 mm |
| #18 | 0.294″ | 19/64″ | 7.47 mm |
| #19 | 0.307″ | 5/16″ | 7.80 mm |
| #20 | 0.320″ | 5/16″ | 8.13 mm |
| #21 | 0.333″ | 21/64″ | 8.46 mm |
| #22 | 0.346″ | 11/32″ | 8.79 mm |
| #23 | 0.359″ | 23/64″ | 9.12 mm |
| #24 | 0.372″ | 3/8″ | 9.45 mm |
| #25 | 0.385″ | 25/64″ | 9.78 mm |
